Printed circuit board assembly is an integral part of various industries

Printed circuit board assembly describes a circuit board after all the components have been attached and installed on a PCB (printed circuit board). A finished PCB is a fully operational electronic device. An electronic assembly uses copper conductors and unique processes to create electrical connections between the selected elements. PCB is most often a mechanical support for electronic components. Its assembly must include a specific set of steps. The steps align with the structure of the bare circuit board, the manufacturing procedures and integrated circuit packaging.

The vital part of PCBA is a high-quality printed circuit board. Its main features are conductive planes, copper traces, pads and insulating material laminated between layers of conductors. The structure has a coat of a non-conductive solder mask and a legend for electronic components. After these construction steps are completed, the bare board is sent into assembly - where PCB wave soldering takes place. After the elements are attached to the board, it is tested.

Printed circuit board assembly process and the techniques

PCBA provides an electrical interconnection between components and ensures they are integrated into an end product. The elements are mounted onto a board through a wave soldering process. In the procedure, melted solder is modified into a required wave through an electromagnetic or mechanical bump. The printed circuit board passes the wave, which attaches the pieces to a board. When it comes to PCB wave soldering, there are three different technologies - THT, SMT or mixed. THT or Thru-Hole Technology assembly can be an automatic or manual process. It only contains three main steps, the first being the placement of the components. Engineers precisely place pieces on a board. The placement must correspond with clients' files and conform to operation standards and regulations.

The second step, which includes inspection and rectification, guarantees a high-quality end product. In this step, it is made sure the elements are placed accurately. The third step is wave soldering, where pieces are secured onto the circuit board. The second technology is SMT or Surface Mount Technology, featuring a completely automatic assembly. The first step is solder paste printing. After the paste is in the correct places, the pick-and-place machine mounts the elements through the reels in the machine.

The last step is reflow soldering, where the pieces pass through a furnace. Mixed technology of printed circuit board assembly is (as the name suggests) the combination of Thru-Hole and Surface Mount Technology. Mixed technology is necessary because electronic products and modern science are becoming increasingly complex, integrated, smaller and complicated.

What is PCB wave soldering, and how does it work?

PCB wave soldering is a unique procedure in which the PCB slowly moves on a conveyor over a wave of liquid solder at a high temperature. The wave flows under the board while applying solder to the leads of elements placed on the board. It was developed in 1956, and then it was a very time-consuming and tedious procedure as the elements had to be attached by hand.

The printed circuit board assembly using the wave soldering procedure consists of four main steps. The first step is applying the flux. A chemical cleaning agent is applied to prevent oxidation of the copper traces when exposed to air. The flux also applies to the bottom of the board before it goes through the wave. Once the flux is applied, it is time for the second step - preheat. It is crucial to preheat the underside to a temperature anywhere from 80°C to 100°C. This step ensures that solvents in the flux evaporate.

The solvent is usually a flammable, volatile organic compound requiring removal before coming into contact with a wave, which is the third step. The board then travels through a wave produced by melting solder ingots in a wave tank. The last step of PCBA is the cool-down period, which ensures secure joints are formed.

Why is PCB wave soldering the best procedure?

PCBA is a paramount part of some of the biggest industries in the world. The PCBs are in slot machines, the automotive industry, aviation and aerospace industries, signalisation and medicine. That is the reason the components must be mounted with precision and great attention to detail. The correct placement determines the effectiveness and the quality of the end product.

There are many advantages of using wave soldering for printed circuit board assembly. The procedure makes manufacturing easy, allows excellent cycle control and can process high-volume, large PCBs. It is a great way to secure boards at high speed with low manufacturing costs and fewer defects possible. PCBA with wave soldering is integral for joining flat surfaces together like panels. That saves time when manufacturing complex designs with limited space constraints.

This assembly also ensures the best consistency and allows for the best quality and standardisation of procedure. Such a process does not only save labour and time but also materials. It improves production efficiency and reduces imperfections and mistakes, all while eliminating the influence and interference of human factors.
